I-Go Folding Scooter
Model |
i-Go™
|
Model Number1 |
S20
|
Weight Capacity | 275 lbs. |
Speed (Maximum)1 | Up to 4 mph at 275 lbs. |
Ground Clearance2 | 3.5 in. at axle |
Turning Radius2 | 45.9 in. |
Reversing Width (K-turn)2 | 49 in. |
Overall Length2 | 44 in. |
Overall Width2 | 20.35 in. |
Tires | Front: 8" Rear: 9" |
Range Per Charge1 | Up to 7 miles at 275 lbs.; Up to 9.3 miles at 220 lbs.4 |
Total Weight Without Batteries2,5 | 60.6 lbs. |
Heaviest Piece When Disassembled | 30.8 lbs. |
Standard Seating | Type: Molded Plastic Material: Polypropylene base and back with seat cushion Width: 16" Depth: 16" |
Drive System | Front-wheel drive, Brushless Hub, 24-volt DC motor |
Dual Braking System | Regenerative and electromechanical |
Battery Requirements3 | 25.2V 9.6 Ah Rechargeable Lithium-Ion Battery |
Battery Weight6 | 4.8 lbs. |
Battery Charger | 3.5 amp, off-board charger |
Freewheel Operational Force | Less than 60 N |
Drive Control Operational Force | Less than 5 N |
Maximum Rated Slope | 6° (10.5%) |
Maximum Obstacle Climbing Ability (Ascending/Descending) | 1.57" |
Seat to Deck Height | 14.61" |
Seat Height | 11.81" |
Overall Height | 36.5" |
Measured Sound Level (A-weighted) | Less than 65 dB |
HCPCS Code | Non-Medical Device* |
Warranty | 3 years on the frame 2 years on electronics except for charger 1 year on motor, battery, and charger |
Color Options | White, Black, Iceberg Blue, Sugar Plum |
1Varies with user weight, terrain type, battery amp-hour rating (Ah), battery charge, battery condition, tire type and tire condition. This specification can be subject to a variance of +10%, -5%. 2Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of (+ or -) 3%. 3Lithium type required. See III. “Batteries and Charging.” 4Results derived from theoretical calculation based on battery specifications and drive system performance. Test conducted at maximum weight capacity. 5Includes standard seat. 6Battery weight may vary based on manufacturer. The information contained herein is correct at the time of publication; we reserve the right to alter specifications without prior notice. *This product is not a medical device and is not intended to assist, treat, diagnose, or alleviate any medical condition or disability. |
